THREAD TYPE:
3/8-24, 7/16-20, 1/2-20, 10x1.25, 10x1.5, 12x1.25, 12x1.50, 12x1.75, 14x1.25, 14x1.50, 14x2.0, 9/16-18, 15x1.25, 16x1.5
HEX:
The main HEX sizes or wheel nut / wheel bolt head sizes available are: 17mm, 19mm, 21mm and 22mm
Not all HEX sizes are available in all thread types.
It is worth while finding out what your current hex size is so that your new wheel nuts or wheel bolts will be compatible in size with the sockets, spanners which are supplied with your cars spare wheel, thus ensuring that you can remove them with your existing tools in the event of a flat tyre at the side of the road.
THREAD LENGTH:
If you are simply replacing your existing bolts with new ones please measure accurately the thread length on your existing bolt to ensure you order the correct replacement ones.
If you need longer wheel bolts than normal please measure the total bolt length you require accurately.
Not every thread length is available we offer a range from 26mm, 28mm, 30mm, 35mm, 39mm, 39mm, 42mm, 45mm, 50mm and 60mm (it is possible to get longer but only for specific applications).
Not all these thread lengths are available in every hex and thread type, use our Wheel Nuts & Bolts Finder or call our sales team
SEAT TYPE:
There are three main wheel nut / wheel bolt seating types, 60 Degrees Taper Cone, Radius Seat or Flat Seat.
The correct nut / bolt seating type is required to ensure that the new nut or bolt seats correctly in your alloy wheel.
